Lighting PCB

What​‍​‌‍​‍‌​‍​‌‍​‍‌ is a lighting PCB?

Lighting PCBs are engineered to be compatible with different types of lights like incandescent, fluorescent, and halogen lamps. Their main function is the distribution of electrical power and they provide a very basic level of control to the lighting systems.

KING FIELD's lighting PCB manufacturing capabilities

Lighting PCB board

Application: LED tube PCB board

Substrate: Aluminum/FR-4

Copper foil thickness: 0.5-6.0 ounces

Surface treatment: OSP/Lead-free HAL/Immersion Gold/Immersion Silver

Flammability: 94 volts

Standards: UL & RoHS

Breakdown voltage: 2.0-4.0KV (AC)

Testing services: Flying probe/AOI/X-ray/100% functional testing

Why choose KING FIELD?

• 20+ years of industry experience

• As a result of its founding in 2017, KING FIELD has gained enormous understanding of PCB fabrication. At present, our business is blessed with a research and development department of 50+ and a production department of 300+ staff. The main criterion of our personnel is that they have on average 20+ years of experience in the PCB/PCBA solutions industry.
• As for PCB manufacturing lines, KING FIELD has installed 7 SMT lines, 3 DIP lines, 2 assembly lines and 1 painting line. The accuracy of our YSM20R placements reaches ±0.015mm and at the same time it supports mounting components as small as 0.1005mm . Our daily production capacities for SMT and DIP are respectively 60 million points and 1.5 million points.

• Quality assurance

When it comes to quality control, KING FIELD holds six main system credentials: IATF 16949, ISO 13485, ISO 9001, ISO 14001, ISO 45001 and QC 080000. To ensure inspection of the process, we have 7 SPI, 7 AOI and 1 X-Ray testing equipment. Our digital MES system guarantees a full traceability of the manufacturing process of each board .

• Transportation support

Shipping domestically is done by SF Express/Deppon Logistics with full coverage; international shipping via DHL/UPS/FedEx with expert shockproof packaging and a triple protective packaging including anti-static, anti-oxidation, and anti-collision protection.

Q1 : How do you solve the heat dissipation problem?

KING FIELD: For lighting with a lot of power, we work with aluminum substrates, and when it comes to lighting with an extremely high amount of power, we also use 3-4oz thickened copper foil. We additionally locate thermal conduction holes under the LED pads .

Q2 : How do you solve the problem of voltage drop over long distance LED strips ?

KING FIELD: Typically, for light strips that are of 10 meters distance or more at KING FIELD, we will make the use of 2-3oz copper foil to lower the resistance level and then accompany it with a dual-terminal power supply design to shorten the current path.

Q3 : How do you prevent sulfide corrosion from causing lamp failure when using outdoor lighting ?

KING FIELD: As far as surface treatment is concerned, we will first decide on immersion gold/silver processes , and then add a nano-protective film that will isolate sulfides ; after that, we will apply a three-proof coating to the whole board , and finally, we will suggest customers to use LEDs capped with anti-sulfurization adhesive.

Q4 : How do you guarantee that the flexible LED strip will not break even after repeated bending?

KING FIELD: In fact, we will prefer rolled copper to electrolytic copper. It has outstanding ductility and it will not produce micro cracks even after repeated bending. For the cases that require three-dimensional bending, we will pick polyimide as the material, and then combine it with a fine circuit design .

Q5 : What qualifications can you provide for your lighting PCBs?

KING FIELD: We can offer a complete set of UL, CE, RoHS, and REACH reports, as well as documentation that complies with the new energy efficiency regulations for ERP systems ​‍​‌‍​‍‌​‍​‌‍​‍‌.
