PCB Assembly Service
As a PCBA manufacturer with over 20 years of professional experience , KING FIELD is committed to providing high-quality, highly reliable PCB Assembly Service solutions to customers worldwide.
☑ 20+ years of PCB assembly experience
☑ Digital MES system enables full traceability
☑ 24 hours - 10 days, from rapid prototyping to mass production
Description
What is a PCB assembly service?
Alongside manufacturing circuit boards, KING FIELD's PCB assembly services provide complete integration of Surface Mount Technology (SMT) and Through-Hole Technology (THT) encompassing the entire range from the prototype phase to large quantity productions. We don't just fabricate circuit boards; we help bring your products to life.
Breadboard Assembly Service
project |
Specific parameters |
SMT production line |
7 high-speed automated SMT production lines |
Component dimensions |
01005 Packaged in large ball grid array (BGA) and square flat no-lead (QFN) packages. |
Mounting accuracy |
±0.015 mm, suitable for fine-pitch components |
Minimum BGA |
Rigid board: 0.3mm; Flexible board: 0.4mm; |
Assembly type |
Surface Mount Technology (SMT) / Through-Hole Technology (THT) / Hybrid Assembly, Turnkey Assembly |
Assembleable PCB board specifications |
Maximum size: 480 x 510 mm; Minimum size: 50 mm x 100 mm |
Minimum QFP pitch |
0.3 mm, supports fine-pitch square flat package (QFP), square flat no-lead (QFN), and chip-scale package (CSP) assembly. |
Reflow oven temperature zone |
10-12 temperature zones, nitrogen reflow soldering, precise temperature control |
Component height limit |
25mm |
Production capacity |
1 million+ components/hour (CPH), high-volume production capacity |
test |
In-Circuit Testing (ICT) / Functional Testing (FCT) / X-ray Inspection, 100% Automated Optical Inspection (AOI), BGA X-ray Inspection, Functional Testing |
Assembly line |
7 SMT and THT production lines; 1-15 day delivery; daily capacity of 60 million points. |
Delivery cycle |
24 hours - 10 days, from rapid prototyping to mass production |
Order Quantity |
Minimum Order Quantity (MOQ) = 0 |
KING FIELD service advantages
- Advanced assembly - Top-tier SMT manufacturing lines with highest precision placement equipment
- Fast delivery - Prototype assembly in 3 days, mass production delivery within 5-10 days
- Quality assurance - Compliant with IPC-A-610, supported by full testing process.
- No minimum order quantity (MOQ), can support production starting from a single piece up to batch production.
- Turnkey solutions - a full service ranging from procurement to final testing
- Quality and certifications - ISO 9001:2015, ISO 14001:2015, ISO 13485:2016, AS9100, UL 796, RoHS, REACH, IPC-6012, IPC-6013, IPC-A-610, IPC-A-600
- Automated Optical Inspection (AOI) after reflow soldering - Automated defect detection using Automated Optical Inspection equipment.
Why choose KING FIELD?
KING FIELD's printed circuit board assembly services include SMT assembly, THT assembly, hybrid technology assembly, complete machine assembly, and complete turnkey solutions including component procurement, testing, and logistics support.
- Speed
- Currently, we have 7 fully automated SMT assembly lines to enable rapid delivery, and we are expanding the scale of our production lines.
- In addition, there are 3 DIP lines, 2 assembly lines, and 1 painting line. The YSM20R has a placement accuracy of ±0.015mm and can handle the smallest 01005 components. The daily SMT capacity is 60 million points. The daily capacity of the DIP lines can reach 1.5 million points. Urgent orders can be delivered within 24 hours, which can respond to customer needs quickly and efficiently .
- 20+ years of PCBA manufacturing experience
For two decades, we've been manufacturing PCB and PCBA, and with a professional technical team of more than 300 people managing quality control, we're able to maintain reliable, long-term component supply chains, offer large-volume, one-stop service, and effectively control costs.
- Comprehensive PCB one-stop service
PCB manufacturing – material procurement – SMT soldering – functional testing – conformal coating – PCB assembly – one-stop service, comprehensively meeting diverse customer needs and providing more efficient, faster, and more comprehensive value-added services for R&D.
- Finished product assembly
Our two finished product assembly lines can offer customers structural component and finished product assembly services, which will further simplify their management processes and reduce the overall cost of finished products.
- Quality assurance
- As far as quality control is concerned, KING FIELD holds six major system certifications: IATF 16949, ISO 13485, ISO 9001, ISO 14001, ISO 45001, and QC 080000.
- Besides, we have 7 SPI, 7 AOI, and 1 X-Ray testing equipment to ensure smooth operation throughout the process. An MES system is used to monitor the production process, real-time data analysis and integration are performed, and our conformal coating meets the requirements of different PCBAs.
- Comprehensive after-sales service
Besides offering product repair, technical support, and handling of customer feedback, King Field also ensures customers receive timely and effective assistance and resolution during product usage.
