Aluminum PCB
With over 20 years of experience in PCB prototyping and manufacturing , KING FIELD prides itself on being your best business partner and close friend, meeting all your PCB needs.
☑ Minimum mechanical aperture: 0.15 mm (1.0 OZ)
☑ Thermal conductivity: 1-5W
☑ Plate thickness: 0.8-3.2MM
Description
What is an aluminum core pcb?
As we all know, aluminum printed circuit boards is a type of metal core printed circuit board (MCPCB), which mainly uses solid aluminum as its base. Because metal core materials have better thermal conductivity and higher heat dissipation efficiency , aluminum pcb board has become the preferred choice for high-power applications such as LED lighting, power electronics, and automotive electronics .
KING FIELD's process capabilities
Aluminum substrate: 1-40 layers
Thermal conductivity: 1-5W
Available structures: double-sided/multi-layered structures
Plate thickness: 0.8-3.2MM
Minimum line width: 0.3mm
Minimum line spacing: 0.3mm
Minimum mechanical aperture: 0.15 mm (1.0 OZ)
Aspect ratio: ≤12:1
Surface treatment types: Immersion gold, immersion nickel palladium gold, immersion silver, immersion tin, OSP, spray tin, electroplating gold, lead-free spray tin
Sheet types: FR-4, Rogers series, aluminum-based
Application areas: New energy vehicles, motorcycles, computers, home appliances, communication electronics, power electronics, industrial control.
Features: Double-sided aluminum base, insulating holes
Project |
Ability |
Substrate: |
FR-4, Rogers series, aluminum-based |
Dielectric constant: |
/ |
Outer copper foil thickness: |
20Z |
Surface treatment method: |
Lead-free tin plating , immersion nickel palladium gold plating, immersion silver plating, immersion tin plating, OSP, tin plating, electroplating gold plating, immersion gold plating |
Minimum line width: |
0.3mm |
Application areas: |
Heat dissipation |
Shelves: |
2nd floor |
Plate thickness: |
1.6mm |
Inner copper foil thickness: |
1 |
Minimum aperture: |
0.15mm |
Minimum line spacing: |
0.3mm |
Features: |
Double-sided aluminum base, insulating holes |
Drilling and through-hole capabilities |
Electroplated through holes, vias and slots (with insulation treatment), blind holes/buried holes, countersunk holes/recessed holes, Z-axis milling, etc. |
Solder resist color |
Green, white, high-reflective white, black, matte black |
Why choose KING FIELD as your aluminum substrate PCB manufacturer?
As a leading manufacturer of metal core circuit boards, KING FIELD focuses on providing high-quality aluminum substrate manufacturing services to meet the diverse needs of customers in different industries.
l Minimum order quantity for aluminum substrate
delivery time from prototyping to mass production of aluminum-based PCBs.
- Prototyping: 24-72 hours
- <20 items : 3-5 business days
- 20-100 items : 5-7 business days
- 100-1000 pieces: 10 business days
- >1000 units: Based on the bill of materials
l 20+ years of PCB manufacturing experience
- Since 2017 , KING FIELD , a high-tech enterprise focusing on one-stop PCB/ PCBA manufacturing, has always been committed to "creating an industry benchmark for ODM/OEM PCBA intelligent manufacturing" and has steadily cultivated the high-end manufacturing field.
- Currently, we have a research and development team of 50+ people and a production team of 600+ people . Our modern factory covers an area of 15,000+ square meters and is equipped with a dedicated aluminum substrate production line.
- Our core team members have an average of 20+ years of practical experience in PCB/ PCBA, covering areas such as circuit design, process development, and production management .
l Transportation support
Domestic shipping is handled by SF Express/Deppon Logistics, with full coverage; international shipping is also available via DHL/UPS/FedEx, with professional shockproof packaging ; and triple protective packaging including anti-static, anti-oxidation, and anti-collision protection.
- After-sales support system
- We promise a 24-hour technical support response time , and each PCB comes with an 18-month warranty (extendable to 36 months) . Our digital MES system permanently stores production data, enabling full-process traceability.
- KING FIELD's quality guarantee:
- ISO 9001:2015 Quality Management System
- IATF 16949 Automotive Quality Management System
- UL certification
- RoHS/REACH environmental certification
FAQ
Q1 : What is the minimum aperture that can be achieved on aluminum substrates?
KING FIELD : The standard minimum aperture is 0.8mm, and with special processes, it can reach 0.5mm . The aperture position tolerance is ±0.05mm.
Q2 : What is the maximum size limit?
KING FIELD : Standard size 600×1200mm, custom sizes available upon request .
Q3 : Do you provide test reports?
KING FIELD : We promise to provide a complete test report for each batch of aluminum substrates , including thermal performance data .
Q4: How do you ensure the signal integrity of aluminum substrates in high-frequency applications?
KING FIELD: We will control the spacing of the grounding via array to ≤λ/10 , and with edge electromagnetic sealing treatment, control the dielectric layer thickness tolerance to within ±3μm , and then use low-loss dielectric materials.
Q5: How do you avoid burrs and aluminum shavings residue when drilling aluminum substrates ?
KING FIELD: We use laser-assisted drilling technology . First, we preheat the aluminum plate to harden the surface layer , then we use diamond-coated drill bits and high-pressure coolant to flush it. At the same time, we use lasers to repair the PCB edges to remove burrs .
